SCR / Thyristor AC Voltage Regulator Module

In Stock

SKU: R3-C-11

SCR / Thyristor AC Voltage Regulator Module

(0) | 0 Reviews | 0 Orders | 0 Wish Listed

₹180.00 (Excluded Tax)

Quantity:

Total price: (Tax : )

Overview
Reviews

Description

The SCR (Silicon Controlled Rectifier) / Thyristor AC Voltage Regulator Module is a high-power AC voltage control board designed to regulate the power supplied to AC loads. Using phase-angle control, the module provides smooth and precise adjustment of AC output voltage through an onboard rotary potentiometer. Large aluminum heatsinks ensure efficient heat dissipation, allowing reliable operation with medium to high-power loads.

This module is suitable for controlling the brightness of incandescent lamps, heating elements, soldering irons, universal AC motor speed, and various industrial or laboratory applications.

Features

SCR/Thyristor-based AC voltage regulation
Smooth rotary knob for precise voltage adjustment
Heavy-duty aluminum heatsinks for improved cooling
High current and power handling capability
Screw terminal connections for secure wiring
Fuse protection for added safety
Compact PCB design
Easy installation and operation
Suitable for resistive and compatible inductive loads

Specifications

Parameter	Value
Product Type	SCR / Thyristor AC Voltage Regulator Module
Input Voltage	AC 110–250V, 50/60Hz
Output Voltage	Adjustable (Approx. 0V to Input Voltage)
Maximum Power	Up to 4000W (with adequate cooling)
Maximum Current	Up to 25A
Control Method	SCR Phase Angle Control
Potentiometer	B100K Rotary Control
Cooling	Dual Aluminum Heatsinks
Protection	Replaceable Glass Fuse
Connection	Screw Terminal Blocks
Mounting	PCB Mounting Holes

Applications

AC Fan Speed Control
Electric Heater Power Control
Soldering Iron Temperature Control
Incandescent Lamp Dimming
Universal AC Motor Speed Regulation
Hot Wire Foam Cutter Control
DIY Electronics Projects
Laboratory Equipment
Industrial Testing
Educational Demonstrations

Advantages

Wide AC operating voltage range
High power handling capability
Smooth voltage regulation
Efficient heat dissipation
Easy screw terminal wiring
Replaceable fuse for protection
Compact and durable construction
Reliable long-term operation

Package Includes

1 × SCR / Thyristor AC Voltage Regulator Module

Safety Instructions

Operates directly from AC mains voltage; use with extreme caution.
Install the module inside an insulated enclosure before use.
Ensure adequate ventilation around the heatsinks.
Do not exceed the rated current or power capacity.
Disconnect power before making wiring changes.
Use only with compatible AC loads.
Keep away from moisture and conductive materials.

Disclaimer

Product appearance, dimensions, and terminal configuration may vary slightly depending on manufacturing batch without affecting functionality or performance.
